Materials: ZnO Wafer Size: 25×25mm,10x10mm,5x5mm
Purity: 99.99% Surface Finish: DSP SSP
Crystal Orientation: <0001>、<11-20>、<10-10>±0.5o Coefficient Of Thermal Expansion: 6.5 X 10-6 /℃ At A Axis, 3.7 X 10-6 /℃ At A Axis
Highlight:

High Energy ZnO Crystal Substrate

,

High Temperature ZnO Crystal Substrate

,

Future Wireless Communication ZnO Crystal Substrate

Product Description

ZnO Crystal Substrate Ideal Material for High Temperature/High Energy Electronic Devices and Future Wireless Communication



our state-of-the-art ZnO Crystal Substrate, the cornerstone for advanced optoelectronic and semiconductor applications. ZnO, renowned for its exceptional electrical, optical, and piezoelectric properties, serves as an ideal platform for developing cutting-edge technologies.

Our ZnO Crystal Substrate showcases exceptional crystal quality, featuring low defect density and high purity. Its wide bandgap and high exciton binding energy make it an outstanding candidate for UV optoelectronics, while its piezoelectric properties enable innovative sensing and energy harvesting solutions.

Engineered for precision, our ZnO substrates offer tight dimensional tolerance and ultra-smooth surfaces, ensuring optimal device performance and reliability. Suitable for a variety of deposition techniques, our ZnO substrates are ready to support your next breakthrough. Elevate your research and production capabilities with our ZnO Crystal Substrate – order now and explore the limitless potential of zinc oxide technology.



ZnO Crystal Substrate Ideal Material For High Temperature / High Energy Electronic Devices And Future Wireless Communication 0

Crystal structure Hexagonal crystal(a=3.252Å,c=5.313Å)
purity 99.99%
Coefficient of thermal expansion 6.5 x 10-6 /℃ at A axis, 3.7 x 10-6 /℃ at A axis
Crystal orientation <0001>,<11-20>,<10-10>±0.5o
dimension 25×25×0.5mm,10×10×0.5mm,10×5×0.5mm,5×5×0.5mm
Surface Finish DSP SSP
Surface roughness ≤5Å
Packing 100 clean bags, 1000 super clean room
