5mol% MgO Doped LiNbO3 Wafers Optimal Material for High-Performance Optoelectronics
Product Details:
| Place of Origin: | China |
| Brand Name: | CSIMC |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Lithium Niobate (LiNbO3) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 20000 pcs/Month |
|
Detail Information |
|||
| Material: | LiNbO3 Wafer | Out Diameter: | 3'', 4'' |
|---|---|---|---|
| Orientation: | X, Z, Etc. | Doping: | 5% MgO:LN |
| Thickness: | 0.25mm - 3mm | Surface Finish: | Single Side Polish, Double Side Polish |
| Polarization: | Yes | Application: | SAW Filter, Ultrasonic Transducer |
| Highlight: | High Performance Optoelectronics LiNbO3 Wafers,5mol% MgO Doped LiNbO3 Wafers,High Performance LiNbO3 Wafers |
||
Product Description
5mol% MgO Doped LiNbO3 Wafers The Optimal Material for High-Performance Optoelectronics
Doped LN Wafers: MgO:LN
the 5mol% MgO-doped LiNbO3 Wafers, the perfect blend of performance and reliability for advanced photonic and optoelectronic applications. By incorporating 5mol% MgO, we've enhanced the traditional properties of LiNbO3, resulting in wafers with superior optical transparency, reduced photorefractive damage, and enhanced thermal stability.
Our MgO-doped LiNbO3 Wafers are meticulously crafted through advanced synthesis techniques and rigorous quality control, ensuring unparalleled crystal quality and surface smoothness. They offer exceptional ferroelectric and piezoelectric properties, making them ideal for applications ranging from optical modulators and frequency converters to high-speed optical switches and integrated photonic circuits.
Experience the next level of performance with our 5mol% MgO-doped LiNbO3 Wafers. Their precision, durability, and versatility promise to deliver unparalleled reliability and accuracy across a wide range of applications. Order yours today and elevate your technology to new heights with our cutting-edge MgO-doped LiNbO3 Wafers.
|
Material |
3" 4" 6" 8" LN wafer (Saw/Optical grade) |
|
Orientation Cut |
Y64°, Y128°, YZ or Customized |
|
Surface finish |
single or double sides polish (DLP/SLP/ SSP/DSP all available ) |
|
Thickness |
0.18/0.25/0.35/0.50/1.00 + mm |
|
TTV |
< 1~5µm |
|
BOW |
± (25µm ~40um ) |
|
Warp |
<= 35µm |
|
LTV (5mmx5mm) |
<1.5 um |
|
PLTV(<0.5um) |
≥98% (5mm*5mm) with 2mm edge excluded |
|
Curie Temp |
1142°C±3°C |
|
Edge Rouding |
Compl't with SEMI M1.2@with GC800# .regular at C typed |
|
Orientation flats |
available, per request |
|
Polished side Ra |
Roughness Ra<=5A |
|
Back Side Criteria |
Roughness Ra:0.5-1.0µm GC#1000 |
|
Cracks, saw marks, stains |
None |
|
Single Domain |
Completed Polarization/Reduced |
FAQs:
- Q: Can you accept product customization?
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
- Q: Can you deliver the goods via our courier agent?
A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.
Acceptance Check
- The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
- After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
- Please open the vacuum package in a clean room when the products are to be applied.
- If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
