4" 5mol% MgO Dope LiNbO3 Wafer For Optical Applications Optimize Your Research And Manufacturing Process
Product Details:
| Place of Origin: | China |
| Brand Name: | CSIMC |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Lithium Niobate (LiNbO3) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 20000 pcs/Month |
|
Detail Information |
|||
| Material: | LiNbO3 Wafer | Size: | 4'' |
|---|---|---|---|
| Orientation: | X, Z, Etc. | Doping: | 5% MgO:LN |
| Thickness: | 0.25mm - 3mm | Surface: | Single Side Polish, Double Side Polish |
| TTV: | <5um | Application: | SAW Filter, Ultrasonic Transducer |
| Highlight: | 5mol% MgO Dope LiNbO3 Wafer,Optical Applications LiNbO3 Wafer,4'' LiNbO3 Wafer |
||
Product Description
4" 5mol% MgO Dope LiNbO3 Wafer For Optical Applications Optimize Your Research and Manufacturing Process
Doped LN Wafers: MgO:LN
The 5mol% MgO-doped LiNbO3 Wafer stands as a pinnacle of material engineering, blending the inherent strengths of Lithium Niobate with the enhancing effects of Magnesium Oxide doping. This precise 5% addition of MgO significantly alters the properties of the wafer, enhancing its resistance to optical damage and improving its overall stability.
Ideal for demanding applications requiring high-performance optical components, the 5mol% MgO-doped LiNbO3 Wafer excels in frequency converters, optical modulators, and other photonic devices. Its improved nonlinear optical response and reduced photorefractive effects make it a sought-after material for researchers and manufacturers alike.
With its robust construction and tailored properties, this wafer is poised to revolutionize the field of optoelectronics. Invest in the future of photonic technology by incorporating 5mol% MgO-doped LiNbO3 Wafers into your designs and projects.
|
Material |
3" 4" 6" 8" LN wafer (Saw/Optical grade) |
|
Orientation Cut |
Y64°, Y128°, YZ or Customized |
|
Surface finish |
single or double sides polish (DLP/SLP/ SSP/DSP all available ) |
|
Thickness |
0.18/0.25/0.35/0.50/1.00 + mm |
|
TTV |
< 1~5µm |
|
BOW |
± (25µm ~40um ) |
|
Warp |
<= 35µm |
|
LTV (5mmx5mm) |
<1.5 um |
|
PLTV(<0.5um) |
≥98% (5mm*5mm) with 2mm edge excluded |
|
Curie Temp |
1142°C±3°C |
|
Edge Rouding |
Compl't with SEMI M1.2@with GC800# .regular at C typed |
|
Orientation flats |
available, per request |
|
Polished side Ra |
Roughness Ra<=5A |
|
Back Side Criteria |
Roughness Ra:0.5-1.0µm GC#1000 |
|
Cracks, saw marks, stains |
None |
|
Single Domain |
Completed Polarization/Reduced |
FAQs:
- Q: Can you accept product customization?
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
- Q: Can you deliver the goods via our courier agent?
A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.
Acceptance Check
- The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
- After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
- Please open the vacuum package in a clean room when the products are to be applied.
- If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
