Elevate Your Optical Components With Our High-Performance C-Plane Sapphire Wafers
Product Details:
| Place of Origin: | China |
| Brand Name: | CSIMC |
| Certification: | ISO:9001 |
| Model Number: | Sapphire (Al2O3) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 Pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette, Jar, Film package |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 10000 pieces/Month |
|
Detail Information |
|||
| Material: | Sapphire (Al2O3) Crystal | Type: | Single Crystal |
|---|---|---|---|
| Color: | White, Transparent | Diameter: | 2" 3" 4" |
| Surface: | Double Side Polish | Young's Modulus (E): | 335 GPa |
| Application: | Semicondutor Wafer, Led Chip, Optical Glass Window, Electronic Ceramics | Industry: | Led，optical Glass，eli-ready Wafer |
| Highlight: | High Performance Sapphire Wafers,Optical Components C-Plane Sapphire Wafers,High Performance C-Plane Sapphire Wafers |
||
Product Description
Elevate Your Optical Components with Our High-Performance C-Plane Sapphire Wafers
the elite choice for tomorrow's technology, where durability meets brilliance. Crafted from pristine sapphire crystal, these wafers represent the epitome of precision and purity.
With their unparalleled hardness and optical clarity, Sapphire Wafers excel in demanding applications such as LED lighting, semiconductor production, and optical components. Their exceptional thermal conductivity ensures reliability and efficiency, pushing the boundaries of what's possible in modern electronics.
Ideal for high-performance devices, Sapphire Wafers guarantee unparalleled quality and longevity. They are the trusted choice for manufacturers seeking to elevate their products to the next level.
Experience the difference that Sapphire Wafers can make for your business. Invest in the future – choose Sapphire Wafers, the key to unlocking innovation and excellence.
OPTICAL PROPERTIES
|
Transmission Range |
0.17 to 5.5 microns |
|
Refractive Index |
1.75449 (o) 1.74663 (e) at 1.06 microns |
|
Reflection Loss |
at 1.06 microns (2 surfaces) for o-ray - 11.7%; for e-ray - 14.2% |
|
Index of Absorption |
0.3 x 10-3 cm-1 at 2.4 microns |
|
dN/dT |
13.7 x 10-6 at 5.4 microns |
|
dn/dm = 0 |
1.5 microns |
PHYSICAL PROPERTIES
|
Density |
3.97 g/cm3 |
|
Melting Point |
2040 degrees C |
|
Thermal Conductivity |
27.21 W/(m x K) at 300 K |
|
Thermal Expansion |
5.6 x 10 -6 /K (parallel C-axis) & 5.0 (perpendicular C-axis) x 10 -6 /K |
|
Hardness |
Knoop 2000 kg/mm 2 with 2000g indenter |
|
Specific Heat Capacity |
419 J/(kg x K) |
|
Dielectric Constant |
11.5 (parallel C-axis) 9.4 (perpendicular C-axis) at 1MHz |
|
Young's Modulus (E) |
335 GPa |
|
Shear Modulus (G) |
148.1 GPa |
|
Bulk Modulus (K) |
240 GPa |
|
Elastic Coefficients |
C11=496 C12=164 C13=115 |
|
Apparent Elastic Limit |
275 MPa (40,000 psi) |
|
Poisson Ratio |
0.25 |
Acceptance Check
1. The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
2. After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
3. Please open the vacuum package in a clean room when the products are to be applied.
4. If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
