4”LiTaO3 The Material that Unlocks the Potential of Temperature-Responsive Innovation
Product Details:
| Place of Origin: | China |
| Brand Name: | CSIMC |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Lithium Tantalate (LiTaO3) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Jar package, vaccum sealed |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 10000 pcs/Month |
|
Detail Information |
|||
| Product: | Thin Film LiTaO3 Crystal | Grade: | Optics Grade |
|---|---|---|---|
| Orientation: | 42Y-cut, 36Y-cut, Z-cut, Etc. | Surface Finish: | Double / Single Side Polish |
| Diameter: | 4inch | Thickness: | 20um, 30um, 50um, 70um, 100um |
| Primary Flat: | 22mm | Application: | Pyroelectric Applications |
| Highlight: | SAW Grade lithium tantalate wafer,Thin Film lithium tantalate wafer,LiTaO3 Wafer 6inch |
||
Product Description
Pyroelectric Marvels: An In-Depth Exploration of LiTaO3's Unique Properties
Welcome to the cutting edge of material science with our exceptional LiTaO3 wafers. These wafers, made from lithium tantalate, offer a unique combination of piezoelectric, pyroelectric, and optical properties, making them indispensable for modern electronics.
LiTaO3 wafers excel in high-frequency applications due to their excellent acoustic and dielectric properties. They are widely used in resonators, filters, and sensors, ensuring precise and reliable performance.
Our wafers are precision-crafted using advanced manufacturing techniques to ensure consistency and quality. With tight tolerances, smooth surfaces, and minimal defects, they are ready to meet the most demanding specifications.
Unlock the power of LiTaO3 with our wafers. Contact us today to learn more about how they can enhance your next electronics project.
|
Product |
Ltihium Tantalate (LT) Wafer |
||
|
Diameter |
3inch |
4inch |
6inch |
|
76.2mm |
100mm |
150mm |
|
|
S/D |
20/10 |
20/10 |
20/10 |
|
TTV |
<3um |
<3um |
<5um |
|
PLTV |
>95% |
>95% |
>95% |
|
Warp |
<20um |
<40um |
<50um |
|
BOW |
<20um |
<30um |
<30um |
|
Ra |
<0.5nm |
<0.5nm |
<0.5nm |
|
Reduction |
Standard White |
Standard White |
Standard White |
|
Dope |
Fe doped |
Fe doped |
Fe doped |
FAQs:
- Q: What are the products you mainly work on?
A: We look at ourselves as the piezo wafer specialist. We are the very first to work with Single Crystal Quartz in China about 30 years ago. Then gradually we step in the field of LiNbO3, LiTaO3, Quartz glass, LGS, CTGS etc. Especially, if you are looking for a piezo quartz supplier, we are the ultimate choice! We export millions of quartz blanks each year because we master the AT, SC and IT cuts with superior angle precision.
- Q: Can you accept product customization?
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
Acceptance Check
- The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
- After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
- Please open the vacuum package in a clean room when the products are to be applied.
- If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
