X-Cut 0.5mm 8 Inch Lithium Niobate Wafer With Surface Roughness Ra 0.5nm
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001 |
| Model Number: | LiNbO3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 PCS |
|---|---|
| Packaging Details: | Cassette or Jar |
| Delivery Time: | 4 Weeks |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Warp: | <40um | TTV: | <5um |
|---|---|---|---|
| Thickness: | 0.5mm | BOW: | <30um |
| Material: | LiNbO3 | Diameter: | 100mm, 150mm, 200mm |
| Surface Roughness: | Ra<0.5nm | Shape: | Round Wafer |
| Highlight: | Lithium Niobate Wafer 8 Inch,X-Cut Lithium Niobate Wafer,LiNbO3 Wafer 0.5mm |
||
Product Description
X-Cut 0.5mm 8 Inch Lithium Niobate Wafer With Surface Roughness Ra 0.5nm
LiNbO3 Introduction
LiNbO3 wafers, also known as lithium niobate wafers, are essential components used in a wide range of applications, particularly in the field of photonics and optoelectronics. These wafers are made from high-purity lithium niobate crystals and possess unique crystal structures and exceptional physical properties.
Product Description:
Lithium-Niobate-Wafer (LiNbO3-Substrate) is an ideal substrate material for various optical applications. Our LN-Wafer is made of LiNbO3 material, with 0.5mm thickness, round shape, and surface roughness Ra<0.5nm. The Total Thickness Variation (TTV) can reach as low as 5um, providing highly precise and consistent optical performance. Our Lithium-Niobate-Wafer can be used in various applications such as optical communication, modulators, and optical switches.
LiNbO3 Features:
- Crystal Structure: LiNbO3 wafers have a perovskite-like crystal structure, which exhibits excellent electro-optic and nonlinear optical properties.
- Transparency Range: LiNbO3 wafers have a broad transparency range from ultraviolet (UV) to near-infrared (IR) wavelengths, making them suitable for various optical applications.
- Electro-Optic Coefficient: LiNbO3 exhibits a high electro-optic coefficient, enabling efficient modulation of light using an electric field.
- Nonlinear Optical Properties: LiNbO3 is characterized by its strong nonlinear optical properties, such as second harmonic generation (SHG) and optical parametric oscillation (OPO), making it valuable for frequency conversion and laser applications.
- Piezoelectricity: LiNbO3 wafers exhibit piezoelectricity, allowing for the conversion of electrical signals into mechanical vibrations and vice versa.
Technical Parameters:
| Parameters | Values |
|---|---|
| Material | LiNbO3 |
| Surface Roughness | Ra<0.5nm |
| BOW | <30um |
| Orientation | X-cut |
| Thickness | 0.5mm |
| Warp | <40um |
| Surface | Polished |
| Diameter | 100mm, 150mm, 200mm |
| TTV | <5um |
| Shape | Round Wafer |
Applications:
BonTek's Lithium-Niobium-Wafer sized from 3 inch to 8 inch. It originates from China and is specially crafted to take the shape of a round wafer with X-Cut Orientation (128Y, 36Y, 64Y, Z cut also available). The thickness of this wafer is 0.5mm and its surface is polished to a smooth finish. The surface roughness of the Lithium Niobate Wafer is Ra<0.5nm, making it ideal for Lithium Niobate Wafer Fabrication.
Packing and Shipping:
LiNbO3 Wafer Packaging and Shipping
Our LiNbO3 wafers are carefully packed in a sealed and secure container with an anti-static layer and moisture barrier to ensure that it arrives securely and undamaged.
The container is then sealed and labeled with a unique identification number for tracking purposes.
We offer both domestic and international shipping options, with the latter requiring additional paperwork. We also provide a tracking number for all domestic shipments.
For further inquiries about our packaging and shipping services, please contact our customer service team.
