200mm LiNbO3 Wafer Substrate For Optical Waveguides And Microwaveguides
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001 |
| Model Number: | LiNbO3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Price: | $500/pc |
| Packaging Details: | Cassette, Jar |
| Delivery Time: | 5-8 weeks |
| Supply Ability: | 300 pcs/month |
|
Detail Information |
|||
| Crystal: | LiNbO3 | Diameter: | 8 Inch; Φ200mm |
|---|---|---|---|
| Orientation: | X-cut, Z-cut | Surface: | Polished |
| Surface Roughness: | Ra<0.5nm | Thickness: | 0.5mm, 0.7mm, 1mm |
| TTV: | <5um | Shape: | Round Wafer |
| Applications: | Optical Waveguides And Microwaveguides | Laser Marking: | Available As Per Request |
| Highlight: | 200mm LiNbO3 Wafer Substrate,Microwaveguides LiNbO3 Crystal,Optical Waveguides LiNbO3 Wafer Substrate |
||
Product Description
Product Description:
8-inch LiNbO3 wafers refer to the specific size of LiNbO3 crystal substrates commonly used in the fabrication of optoelectronic devices and integrated circuits. These wafers are made from high-purity lithium niobate crystals and offer several advantages due to their larger size. Here is a description of 8-inch LiNbO3 wafers:
- Size: 8-inch LiNbO3 wafers have a diameter of approximately 200 millimeters (8 inches), making them larger than smaller-sized wafers like 4-inch or 6-inch wafers. The larger surface area of 8-inch wafers allows for higher device density and increased production efficiency.
- Thickness: The standard thickness of 8-inch LiNbO3 wafers ranges from 0.5 to 1 millimeter. However, custom thicknesses can also be obtained based on specific application requirements.
- Crystal Orientation: 8-inch LiNbO3 wafers can be cut and oriented along different crystal planes, typically the Y- and X-cut orientations, which are commonly used in many optoelectronic devices. However, other crystal orientations may also be available depending on the specific application needs.
- Advantages: The larger size of 8-inch LiNbO3 wafers offers several advantages:
Increased Device Capacity: The larger surface area allows for a higher number of devices and integrated circuits to be fabricated on a single wafer, thereby improving production capacity and yield.
Enhanced Integration: With a larger area, 8-inch wafers enable higher device integration and improved performance due to the availability of more real estate for components and interconnects.
Improved Uniformity: The manufacturing process for larger wafers often results in better consistency and uniformity across the wafer, contributing to improved device performance and yield.
- Availability: 8-inch LiNbO3 wafers are commercially available from various specialized semiconductor material manufacturers. These suppliers provide ready-made 8-inch wafers or offer customization options to meet specific application requirements.
Applications:
8-inch LiNbO3 wafers find applications in various fields where their unique optical and electro-optic properties are utilized. For example: Optical Modulators, Frequency Conversion, Acousto-Optic Devices, Integrated Optics, Nonlinear Optical Devices, Optical Sensors.
Packing and Shipping:
LiNbO3 Wafers should be packaged and shipped in accordance with the following guidelines:
- LiNbO3 Wafers should be packaged in an antistatic bag.
- The package should be padded with cushioning material to protect against shock.
- The package should be clearly labeled with the product name and the contents of the package.
- The package should be sent by a reputable courier service.
- The package should be tracked and insured.
