Ultra Thin Lithium Tantalate Crystal Pyroelectric Infrared Detector Sensitive Layer
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Lithium Tantalate (LiTaO3 crystal) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 10000 pcs/Month |
|
Detail Information |
|||
| Product: | Piezoelectric LiTaO3 Crystal | Material: | Ultra-thin LiTaO3 |
|---|---|---|---|
| Property: | Pyroelectricity | Orientation Cut: | (0001) Z Axis |
| Size: | Dia. 1''~3'' OR Squard | Application: | Pyroelectric Detectors |
| Surface: | Double Side Polish | Roughness: | Ra<1nm |
| Highlight: | Ultra Thin Lithium Tantalate Crystal,Sensitive Layer Lithium Tantalate Crystal,Pyroelectric Infrared Detector Crystal Wafer |
||
Product Description
Ultra Thin Lithium Tantalate Crystal As Sensitive Layer In Pyroelectric Infrared Detector
Lithium tantalite (LiTaO3) presents unique electrooptical, acoustic, piezoelectric, pyroelectric and non-linear optical properties, making it a suitable material for applications in pyroelectric infrared detector. The z-cut single crystal LiTaO3 shows more advantages as a new type of optical material than other traditional optical substrate materials, such as large pyroelectric coefficient, small dielectric constant, high curie temperature and uniformity of crystallinity.
The scratch on crystal surface would affect the absorption coefficient of the wafer, the noise equivalent power value (NEP) and voltage responsivity Rv of the detector.
| Material |
3" 4" 6" 8" LN wafer SAW / Optical |
3" 4" 6" LT wafer SAW / Optical |
| Orientation |
X/Z/Y41°/Y64°/Y128°/YZ/YX or Customized |
X112°/Y28°/Y36°/Y42°/YZ or Customized |
| Surface finish |
Single Side Polish or Double Sides Polish (DLP/SLP/ SSP/DSP all available ) |
|
| Thickness | 0.18/0.25/0.35/0.50/1.00 mm | 0.25/0.35/0.50/1.00 mm |
| TTV | < 1~5µm | |
| BOW | ± (25µm ~40um ) | |
| Warp | <= 35µm | |
| LTV (5mmx5mm) | <1.5 um | |
| PLTV(<0.5um) | ≥98% (5mm*5mm) with 2mm edge excluded | |
| Curie Temp | 1142°C±3°C | 605°C±3°C |
| Edge | Compl't with SEMI M1.2@with GC800# .regular at C typed | |
| Orientation flats | available, per request | |
| Doped with |
Er, MgO Single or Double doped |
Fe doped |
| Polished side Ra | Roughness Ra<=5A | |
| Back Side Criteria | Roughness Ra:0.5-1.0µm GC#1000 | |
| Edge Rounding | Compliant with SEMI M1.2 Standard/refer to IEC62276 | |
| Cracks, saw marks, stains | None | |
| Single Domain | Completed Polarization / Reduced | |
