4'' 6'' LiNbO3 LiTaO3 Quartz Piezoelectric Wafers Surface Polished For SAW And BAW Use
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Piezoelectric Wafer |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 50000 pcs/Month |
|
Detail Information |
|||
| Product: | Piezoelectric Wafer | Diameter: | 3 Inch, 4 Inch, 6 Inch, 8 Inch |
|---|---|---|---|
| Material: | Crystal Quartz, Lithium Niobate, Lithium Tantalate | Thickness: | 0.10mm, 0.35mm, 0.5mm |
| Primary Flat: | 32.5±2mm, 47.5±2mm, NOTCH | Surface: | Polished |
| Application: | SAW And BAW | Inspection: | TTV, BOW, Warp, Ra, S/D |
| Highlight: | 4'' Piezoelectric Wafer,Quartz piezo wafer,6'' Piezoelectric Wafer |
||
Product Description
4'' 6'' LiNbO3 LiTaO3 Quartz Piezoelectric Wafers Surface Polished for SAW and BAW Use
Piezoelectric effect materials are those which can generate electricity on the application of force or pressure and the reverse effect can also happen. Piezoelectric materials have non-conductive nature and they can be classified as ceramics and crystals.
BonTek grows crystal and fabricate wafers, we are piezoelectric specialist. We work mostly with wafers, blanks, substrates made from Quartz Crystal, Lithium Niobate, Lithium Tantalate, Fluoride, Glass etc.
|
Material |
Lithium Niobate | Lithium Tantalate | Quartz Crystal |
|
Size |
3’’, 4’’, 6’’, 8’’ | 3’’, 4’’, 6’’ | 3’’, 4’’, 5’’, 6’’, 8’’ |
|
Cut Angle |
X / Y / Z 41Y / 64Y／128Y |
X / YZ / X112 28Y / 36Y / 42Y |
X / Y / Z AT36 / ST42.75 |
|
Surface Finish |
Single side polish / Double side polish | ||
|
Thickness |
0.08mm / 0.25mm / 0.35mm / 0.50mm / 1.00mm / 2.00mm | ||
|
TTV |
< 5um | ||
|
PLTV |
>98% (5mm*5mm) | ||
|
LTV |
< 1.5um | ||
|
Bow |
-25um < bow < ＋25um | ||
|
Warp |
< 30um | ||
|
Curie Temperature |
1142℃ ± 2℃ | 605℃ ± 2℃ | 573℃ |
|
Edge Profile |
CompI’t with SEMI M1.2 @ with GC#1000, GC#2000 | ||
|
Orientation Flat |
22±2mm, 32.5±2mm, 47.5±2mm, 57.5±2mm, Notch As per request |
||
|
Dope |
Er, MgO | Fe | with or without seed |
|
Front Side |
Roughness Ra<= 10A | ||
|
Back Criteria |
Roughness Ra: 0.2--0.7um GC#1000, GC#2000 | ||
|
Appearance |
No Cracks, saw marks, stains | ||
|
Single Domian |
Completed Polarization / Reduced | No Stress | |
