4'' 6'' Fused Silica Wafer 500um SiO2 HPFS with Excellent Chemical Resistance
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Fused Silica, Fused Quartz |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 20000 pcs/Month |
|
Detail Information |
|||
| Material: | Fused Silica Wafer | Type: | High Purity Fused Silica |
|---|---|---|---|
| Brand: | JGS1, JGS2, JGS3 | Dia.: | 50.8mm, 76.2mm, 100mm, 150mm |
| Thickness: | 0.35mm, 0.50mm | Transmission: | Ultraviolet And Visible |
| Surface: | DSP, SSP | Roughness Ra: | <1nm |
| Highlight: | 6'' Fused Silica Wafer,500um SiO2 Wafer,4'' Fused Silica Wafer |
||
Product Description
High Purity Fused Silica Wafer 4'' 6'' 500um SiO2 HPFS with Excellent Chemical Resistance
Fused Silica (SiO2) wafers are made from high purity fused silica, ground and polished to optical grade on both sides. The fused silica wafers are suitable for many optical applications because of their excellent optical transmission characteristics. Fused silica also has excellent chemical resistance against a wide variety of solvents, as well as exceptional heat resistance, with high dimensional stability over a wide temperature range thanks to its ultra low thermal expansion coefficient.
|
Material |
High Purity Fused Silica |
|
Diameter |
76.2 +/- 0.1mm, 100 +/- 0.1mm, 150 +/- 0.1mm |
|
Thickness |
500 +/- 25 um500 +/- 25 um |
|
Primary Flat |
22.5 +/- 2.0 mm, 32.5 +/- 2.0 mm |
|
Surface |
Double Side Polished (DSP) with surface roughness Ra < 1 nm |
|
S/D |
40/20, 60/40 |
|
TTV |
< 5 um, < 10 um |
|
Edge |
with Bevel, C shape |
|
Fused Silica |
|||
|
Mechanical |
Units of Measure |
SI/Metric |
(Imperial) |
|
Density |
gm/cc (lb/ft3) |
2.2 |
-137.4 |
|
Porosity |
% (%) |
0 |
0 |
|
Color |
— |
clear |
— |
|
Flexural Strength |
MPa (lb/in2x103) |
— |
— |
|
Elastic Modulus |
GPa (lb/in2x106) |
73 |
-10.6 |
|
Shear Modulus |
GPa (lb/in2x106) |
31 |
-4.5 |
|
Bulk Modulus |
GPa (lb/in2x106) |
41 |
-6 |
|
Poisson’s Ratio |
— |
0.17 |
-0.17 |
|
Compressive Strength |
MPa (lb/in2x103) |
1108 |
-160.7 |
|
Hardness |
Kg/mm2 |
600 |
— |
|
Fracture Toughness KIC |
MPa•m1/2 |
— |
— |
|
Maximum Use Temperature (no load) |
°C (°F) |
1100 |
-2000 |
|
Thermal Conductivity |
W/m•°K (BTU•in/ft2•hr•°F) |
1.38 |
-9.6 |
|
Coefficient of Thermal Expansion |
10–6/°C (10–6/°F) |
0.55 |
-0.31 |
|
Specific Heat |
J/Kg•°K (Btu/lb•°F) |
740 |
-0.18 |
|
Dielectric Strength |
ac-kv/mm (volts/mil) |
30 |
-750 |
|
Dielectric Constant |
@ 1 MHz |
3.82 |
-3.82 |
|
Dissipation Factor |
@ 1 MHz |
0.00002 |
-0.00002 |
|
Loss Tangent |
@ 1 MHz |
— |
— |
|
Volume Resistivity |
ohm•cm |
>1010 |
— |
